Breakthrough Fire-Resistant Coating Transforms Steel Safety Standards

In a significant breakthrough for fire safety in construction, researchers have developed a new epoxy-based intumescent fire protective coating that offers superior protection for steel surfaces.

This innovative coating - which is formulated with a specific ratio of ammonium polyphosphate (APP) and copper oxide (Cu₂O) - promises to outperform conventional fire-resistant solutions.

The core composition of the coating is based on epoxy resin (EP), enhanced with varying ratios of APP and Cu₂O to achieve optimal fire resistance.

Extensive testing involved applying a 2 mm thick layer of the coating to steel plates. The most effective results were observed with a 6:4 APP to Cu₂O mass ratio.

This particular formulation successfully reduced the backside temperature of the coated steel plate to 234.5 °C, significantly below the critical failure threshold for steel, which is approximately 500 °C. For comparison, uncoated steel plates reached a dangerous backside temperature of 529 °C.

Beyond its exceptional thermal protection capabilities, the optimised coating formulation also significantly mitigates fire-related hazards. According to cone calorimetry tests, which realistically simulate fire conditions, the new coating demonstrated an impressive 80% reduction in peak heat release rate.

Total smoke production was reduced by 59.5%, and peak carbon monoxide (CO) production dropped by 75%. These substantial reductions in heat, smoke, and CO emissions showcase the coating's effectiveness in fire safety.

The APP/Cu₂O system's remarkable ability to form an intumescent layer with high expansion and superior insulation properties acts as a robust barrier, protecting the steel substrate from extreme temperatures and structural failure during a fire.

The development sets a new benchmark for fire safety in construction and industrial applications. Steel, a critical material in building infrastructure, requires reliable fire protection to maintain structural integrity under high-temperature conditions.

This new coating not only offers enhanced fire resistance but also contributes to reducing environmental impact by lowering smoke and toxic gas emissions.

The implications of this research are far-reaching, offering a safer and more resilient solution for protecting steel structures in various settings. As the industry continues to evolve, innovations like this will play a crucial role in ensuring the safety and longevity of critical infrastructure.
